“In the Split Body tool, you can now use Local Slicing to split a solid with a cylindrical surface! Previously, only planar faces, datum planes, and their edge loops were selectable.” This is like the Pull Edge user-interface in Sheet Metal and sets the point where the simulated cutter will stop.” Splitting a face using a curved surface
With an edge selected, when you click the Chamfer option in the Pull tool, the edge ends switch to yellow cones that can be dragged. “Stop Chamfers have conical stop faces that mimic the effect of an angled cutting tool rotating and coming-to-a-stop in the middle of an edge. Most of them seem to be general improvements and refinements to 3D model editing. Advanced chamfers in DesignSpark Mechanical 4.0 By going through their release notes document, which actually is literally 79 pages long, there are plenty of detailed changes. What are the new features in DesignSpark 4.0? Honestly, there is almost too much to tell.
